Video Gallery

INACHUS 3D laser imaging by ONERA


3D Laser Imaging demo by ONERA. This demo took place at the INACHUS plenary meeting at Gardane (June 10, 2015).

INACHUS Radar Doppler demonstration by CINSIDE


Radar doppler demonstration by CINSIDE. This demo took place at the INACHUS plenary meeting at Gardane (June 10, 2015).

INACHUS Building collapse simulation by LUAS



Structural simulation of a building exposed to a terrorist attack using a custom constraint system and a real world parameters

1st field test overview

Video from the INACHUS first field test held in June 2016 in Agesta (Sweden).

INACHUS robot @ 1st field test



INACHUS robot was tested by end users during the first pilot of the INACHUS project in Stockholm, Sweden.

INACHUS 3D mapping

Wide Area Surveillance by camera and laser scanner from ground and aerial measurements - First experiments on a shared scenario at ONERA Toulouse, France.

INACHUS 3D mapping from UAV



During the INACHUS WP4 (Wide -Area Surveillance Tools for Monitoring of Collapsed Buildings) technical meeting (March 14th in Toulouse, France) two drones for 3D mapping were deployed by our partner ITC (University of Twente, The Netherlands): the Aibot X6 and the Phantom Vision 2. The video is an 3D animation from the flight.

INACHUS 3D laser imagery tests by ONERA

ONERA contributes to the 3D model of the church "Basilique Saint Sernin" in Toulouse. The video represents a 3D data fusion and registration between the 3D Laser cameras data and the colored images (co-located instruments on the ground). This experiment is a first step to test and validate the 3D data fusion algorithms based on Laser solution.

INACHUS - Pyne Gould Building Collapse Simulation



Inachus Partner “Applied Science International” (ASI) has concluded modeling the Pyne Gould Building using its structural analysis software “Extreme loading for Structures” (ELS). The Pyne Gould Building collapsed due to the 6.3 magnitude earthquake in Christchurch, New Zealand.

INACHUS - Pyne Gould Building Collapse Simulation


The Pyne Gould Building collapsed due to the 6.3 magnitude earthquake in Christchurch, New Zealand in 2011. This analysis was done as part of Work Package 3 activities to provide the shape of the debris field of the collapsed structure and the location of large cavities. This assists USaR teams in identifying the most likely location of survivors trapped beneath the debris.

Building 3 Partial collapse simulation 3D view by ASI



INACHUS Partner "Applied Science International" (ASI) has performed the simulation analysis of the partial collapse of a generic Residential Highrise Building due an explosion scenario.
The video shows the 3D view of the analysis results.
This analysis was done as part of Work Package 3 activities to the shape of the debris field of the collapsed structure and the location of large cavities.

Building 3 Total collapse simulation 3D view by ASI



INACHUS Partner "Applied Science International" (ASI) has performed the simulation analysis of the collapse of a generic Residential Highrise Building due an explosion scenario.
The video shows the 3D view of the analysis results.
This analysis was done as part of Work Package 3 activities to the shape of the debris field of the collapsed structure and the location of large cavities.
This assists USaR teams in identifying the most likely location of survivors trapped beneath the debris.

Building 4  collapse comparison simulation 3D view by ASI



The video of the results obtained by ASI Europe team in modeling collapse of structures, as part of the INACHUS project, during the second field test in Lyon, France, on May 31, 2017. The video shows a side by side comparison between ELS analysis (ELS - Extreme Loading for Structures - http://www.extremeloading.com ) done by one of ASI's engineers prior the demolition and the real RC structure while is manually demolished by an excavator with a hammer attachment.

INACHUS, a wonderful overview of the 2nd pilot.



This video is a nice overview of the landscape and  the successful 2nd Pilot which took place in Lyon, France. The Consortium of INACHUS greeting you in the last seconds of the video.

INACHUS, Robot Demonstration
INACHUS, Radio report
by Eva Karnofsky for the WDR5 Morgenecho about the 3rd pilot demonstration of Inachus on 20/04/2018 at the Training Base Weeze, Germany
